Technical Specifications

Dimensions

Head Dia.
2.4 inches (62 mm)
Body Dia.
1.4 inches (37 mm)
Length:
9.1 inches (232 mm)
Weight:
13.4 ounces (381 grams)
w/o battery
23.2 ounces (659 grams)
w/ battery

Battery Type

  • 2x32650 li-ion battery pack (included)
  • Only use the li-ion built-in charger to charge EAGTAC original 7.4V battery pack (more)
  • Read battery safety precaution

Operating voltage

  • 5V - 8.4V
  • Read more about operating with individual or non-rechargeable batteries

What's included

  • MX25L2-C flashlight
  • Spare o-rings
  • User Manual
  • Spare waterproof charging cap
  • 7.4V li-ion battery pack (R44) 6000mAh capacity, 44.4Wh, IC protected
  • 12V car charger adapter w/ 6 foot heavy duty high current cord

Two models

  • Base model
    • Smooth aluminum head
  • Kit model
    • Stainless steel bezel
    • ET54II Diffuser filter w/flip cover
      (YRGB w/flip cover also available as option)
    • Rigid nylon holster w/ self-retention device
    • UL/PSE ceritifed 18W wall charger (10V 1.8A)
    • EU only: TUV/CE certified 18W wall charger (10V 1.8A)

Carrying method

  • Para-cord lanyard with quick attachment clip
  • Heavy duty nylon holster

Waterproof

  • IPX-8 standard

Replaceable items

  • Lens

LED

  • 3 * CREE XP-L HI V3 Cool White LED
  • 3 * CREE XP-L HI V2 Neutral White LED

Max output

  • CREE XP-L HI V3 Cool White LED
    • LED lumen: 3445
    • ANSI FL-14 lumen: 2606

Beam Profile

CREE XP-L HI V3 Cool White LED

  • Center lux: 87,500 lux
  • Center spot angle: 5.7°
  • Spill light angle: 59°
  • Beam distance: 645 yards / 592 meters
                    Mouse over to enlarge

Lens

  • Waterwhite glass lens w/ harden treatment
  • Anti-reflective (AR) coating on both side (96% transparency)

LED circuit

  • C9500 SEL
    • Highest efficiency current mode controller from Linear Technology
    • Synchronous buck w/ efficiency of up to 95%
    • Non-dimming constant current regulation for all output levels
    • Very low standby current (uA)
    • Turbo boost technology5

Charging circuit

  • C2000 SW II
    • Highly efficient step-down charging IC
    • Voltage input 10V - 15V
    • Compatible with 12V automobile DC socket
    • Constant current and constant voltage charging method
    • Fast charge to 35% in one hour
    • Very high charging voltage accuracy (1%)
    • Small current charge for low voltage battery
    • No trickle charge when battery is full
    • Automatically ends charging when charging current reduces below 10%

Reflector

  • Triple smooth aluminum reflector

Material

  • HAIII hard anodization aerospace aluminum

Output and Runtime

  • Four brightness levels (Regular mode)
    • Led lumen: 34455-2790/1650/381/27
    • ANSI FL-1 lumen: 26065-2180/1290/299/22
    • Runtime: 1.3/3.2/16/200+ hours (R44)
  • Two brightness levels (Tactical mode)
    • Led lumen: 34455-2790/720/Strobe I/Strobe II
    • ANSI FL-1 lumen: 26065-2180/570/Strobe I/Strobe II
    • Runtime: 1.3/8.5 hours (R44)
  • Seven hidden auxiliary outputs7
    • Strobe/Strobe(Var)/Flash(Hi)/S.O.S.(Fast)/S.O.S./Beacon/Flash(Lo)

Operations

Basic operations:
  • Basic - Turn on the light by press and release the on/off button switch (<0.4s). to turn off the light, press and release the switch again.
  • For momentary on, press and hold the button switch for immediate output.
  • Twist the head to select between four output levels. You can pre-select the desired output level before turning on the flashlight.
  • Instant Turbo output - at any output level, press and hold the flashlight for 100% output. Release the button to return to previous level.
  • Instant Strobe output - at any output level (or off), double press and hold the on/off button switch for strobe output. Release the button to return to previous level (or off).
  • To access auxiliary levels, starting at head tight position (1st level), loosen to 3rd (or 4th level) and tighten the head within one second to enter auxiliary setting. Repeat to cycle through all settings. Turn off the light or loosen the head to quit.
  • Advance (Programmable Features) To switch between tactical and regular mode, turn on the flashlight at 1st level, dial to 2nd level and then back to 1st level for five times within five seconds.


Controls

Other features

  • LED direct soldering on copper for maximum heatsink ability
  • User replaceable glass lens
  • Power gauge
  • Turbo boost technology
  • Battery reverse polarity protection
  • Tail stand

Warranty

Battery Safety Precaution

Ensure the protective circuit on the 18650 batteries has current limitation of higher than 5A. Always use proven EAGTAC batteries for best performance and reliability.

All EAGTAC flashlights are designed to use button-top battery (battery with protruding positive terminal). For rechargeable li-ion battery, use only EAGTAC li-ion battery, or other protected li-ion battery with compatible length and diameter. Before using the battery, check and ensure the battery outer wrapping (the isolating plastic film that wraps around the metal housing of the battery) is complete. Broken battery wrapping may lead to short circuit and damage to the flashlight.

Lithium and Li-ion battery can explode or cause burns if disassembled, shorted, or exposed to high temperature. Do not mix new and used batteries. Do not mix batteries with different brand, capacity, voltage, or install batteries backwards.

NiMH rechargeable battery may release gas during discharge. If you experience an inflated switch boot or find high pressure being built inside the flashlight, switch off the flashlight immediately. Slowly loosen the tail-cap to reduce the internal pressure and replace all batteries.     Back to top

Flashlight Maintenance

Periodically clean the threads and o-rings with a lint free cloth and apply a thin coating of EAGTAC synthetic grease to the o-rings and threads. After prolonged exposure to moisture, the head and batteries should be removed, inspected, and dried. Do not touch or attempt to clean the reflector, as it will scratch the reflective coating permanently.     Back to top

  1. This weight measurement is based on the Kit model excluding batteries
  2. All batteries must have protruding top button.
  3. Beam output diameter taken at one meter
  4. ANSI FL-1 Lumens is a measurement of light output standardized by American National Standards Institute for use with flashlights. This ANSI Lumen measurement is the total overall light output being emitted from the flashlight. This measurement is generally more accurate as it takes into consideration the loss from reflector/lens/bezel. EAGTAC’s ANSI Lumen output is measured using a calibrated integrated sphere three minutes after turning on the flashlight. For O.T.F. lumen, measurement is taken one minute after turning on the flashlight.
  5. Energy saving feature reduce the maximum output current from 100% to 85% after 200 seconds at turbo output.
  6. Runtime is measured using three EAGTAC 3500mAh high discharge 18650 li-ion batteries.
  7. Maximum efficiency occurs when input voltage is very close to LED forward voltage.
